5.1 Spectrum radEAGLE User Manual
Self Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . see 5.27, p. 80
About . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . see 5.28, p. 81
Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . see 5.29, p. 82
Spectrum . . . . . . . . . . . . . . . . . . . . . . . . see 5.1, p. 42
Basic Settings . . . . . . . . . . . . . . . . . . . . see 5.2, p. 47
Easy Calibration . . . . . . . . . . . . . . . . . . . see 5.14, p. 63
Protected Settings . . . . . . . . . . . . . . . see 5.15, p. 65
Collect Reachback . . . . . . . . . . . . . . . . see 5.25, p. 76
Send Data . . . . . . . . . . . . . . . . . . . . . . . . see
5.26, p. 78
Self Test . . . . . . . . . . . . . . . . . . . . . . . . . see 5.27, p. 80
About . . . . . . . . . . . . . . . . . . . . . . . . . . . . see 5.28, p. 81
Shutdown . . . . . . . . . . . . . . . . . . . . . . . . see 5.29, p. 82
Figure 33: The advanced operations menu
Settings and Commands
Exit
Return to the superior screen.
Down
Highlight the next item. Cycles to the top item after you reached the last item.
Select
Select the highlighted item.
5.1 Spectrum
The screen (Fig.
34, p. 43) shows a spectrum and provides access to commands to acquire
and manage spectrum data and to influence the display and analysis of spectra.
Settings and Commands
Next
Cycle through the commands available to work with the spectrum. This command is
always available, the commands for the other two keys change.
Start • Stop
Start or stop the acquisition of spectrum data. The current status is shown in the
chart (Fig. 34, p. 43).
42/147 Software 3.2.12 • Document 3.3.0o © innoRIID GmbH • 2019-04-11
