List of Figures
1 Annotated top view of the radEAGLE instrument . . . . . . . . . . . . . . . . . 14
2a Rear view of the radEAGLE with open latch (standard housing) . . . . . . . . . 15
2b Rear view of the radEAGLE with open battery compartment (underwater housing) 15
3 Name plate on the rear latch of the radEAGLE . . . . . . . . . . . . . . . . . . 15
4 The radEAGLE in the standard case . . . . . . . . . . . . . . . . . . . . . . . . 16
5 The radEAGLE in an optional watertight case . . . . . . . . . . . . . . . . . . . 17
6 The radEAGLE with accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
7 Standard (left) and optional watertight cases for the radEAGLE . . . . . . . . . 18
8 Anatomy of the radEAGLE display . . . . . . . . . . . . . . . . . . . . . . . . . . 21
9 The current functions of keys shown along the bottom of the radEAGLE display. 24
10 Cycling command pairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
11 A menu with the third item accented . . . . . . . . . . . . . . . . . . . . . . . . 25
12 Changing switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
13 Changing values by choosing from a list . . . . . . . . . . . . . . . . . . . . . . 26
14 Entering the password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
15 After entering the password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
16 Status bar after saving a screenshot . . . . . . . . . . . . . . . . . . . . . . . . 28
17 Box with potassium chloride (KCl) for stabilization and calibration . . . . . . . . 29
18 Starting the radEAGLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
19 Initial stabilization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
20 Initial Stabilization after identification of the stabilization source . . . . . . . . . 30
21 Dose rate display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
22 Dose rate display with gamma warning . . . . . . . . . . . . . . . . . . . . . . . 32
23 Dose rate display with gamma alarm . . . . . . . . . . . . . . . . . . . . . . . . 32
24 The Easy ID screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
25 The Easy ID results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
26 Detect mode background measurement . . . . . . . . . . . . . . . . . . . . . . 34
27 Detect mode chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
28 Detect mode: Approaching a source . . . . . . . . . . . . . . . . . . . . . . . . 35
29 Detect mode: Close to a source . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
30 A warning reported on screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
31 An alarm reported on screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
32 An neutron alarm reported on screen . . . . . . . . . . . . . . . . . . . . . . . 39
© innoRIID GmbH • 2019-04-11 Software 3.2.12 • Document 3.3.0o 7/147
