OutBack Power MATE3 User Manual

Programming
130 900-0117-01-00 Rev B
Erasing Data Logs for the FLEXnet Battery Monitor
Figure 155 Erasing a Data Log for the FLEXnet DC Battery Monitor
Figure 156 Data Log Example for the Charge Controller
Figure 157 Data Log Example for the FLEXnet DC Battery Monitor
Date In AH In kWh Out AH Out kWh Net AH Net kWh Min SOC
6/13/11 0 0 1 0.01 -1 -0.01 99
6/12/11 81 2.17 9 0.11 72 2.06 98
6/11/11 63 1.67 9 0.12 54 1.55 98
NOTE: This header line is included in the download.
Date AH Kwh
Max
Amps
Max
Watts
Absorb
Time
Float
Time
Min
Battery V
Max
Battery V
MAX
VOC
6/13/11 0 0 1.2 29 0:00 0:00 24.1 29.1 122
6/12/11 38 0.9 5.5 143 0:00 0:00 24.1 29 122
6/11/11 32 0.8 5.6 144 0:00 0:00 24.1 28.7 120
NOTE: This header line is included in the download.
To erase a Data Log for the FLEXnet DC Battery
Monitor:
1. Access the
Main Menu as shown in Figure 71.
2. Select the
Device Data Logs menu.
3. Select FLEXnet Battery Monitor .
4. Select Erase Data Log on the FN Battery Monitor
Data Log menu.
5. Select <Yes> to erase the data log. Press <No> to
return to the FN Battery Monitor Data Log menu.
Press <Continue> to return to the
Main Menu .
Returns to the Upload and
Save Data Log screen.
