Troubleshooting
138 900-0117-01-00 Rev B
Event Messages
The Events LED indicates that an event has occurred which requires attention. If this LED illuminates,
follow the steps illustrated in Figure 166 to help determine the nature of the fault and may help resolve it.
Figure 165 Event Notification
Look
Chec
System Indicator Legend
OK
System Operational
!
Check Battery (with FNDConly)
X
Battery Critical (with FNDConly)
!
Check Generator (Off Grid system type only)
!
Check Inverter
!
Check Utility Grid
(with a Grid Tied system type only)
These system indicators are often specific to certain products or system
configurations, as noted in the table. See pages 34 through 36 for details.
