900-0117-01-00 Rev B 29
Operation
The MATE3 provides the means for programming OutBack inverter/chargers, charge controllers, and
battery monitors when pre-programmed default settings do not work for the destined installation.
IMPORTANT:
The OutBack inverters have non-volatile memory and will retain any settings
that have been changed, even after the MATE3 is removed. If a system does
not have a MATE3, an installer can bring a MATE3 to the site temporarily,
install it, change the settings, and then remove it.
IMPORTANT:
Some functions are not based in the inverter or charge controller, but are
part of the MATE3’s firmware. They will not function if the MATE3 is
removed. These functions are listed beginning on page
14
105.
Display and LED Status Indicators
Figure 18 Display and LED Status Indicators
Battery Status LEDs (x3)
LCD Screen
Inverter LED
Charger LED
Generator LED
Events LED
AC Input LED
Favorite LED
