900-0117-01-00 Rev B 141
Specifications
Mechanical Specifications
Mechanical Specification MATE3
Dimensions
(H x W x D)
7 1/2”
x 7 1/16” x 1 5/8”"
(19 x 17.9 x 4.2 cm)
Shipping Dimensions
(H x W x D)
3 ¼ x 9 x 13 ½”
(33.7 x 22.9 x 34.3 cm)
Weight
1.4 lbs
(0.64 kg)
Shipping Weight
3.0 lbs
(1.36 kg)
Ports
RJ45 for proprietary OutBack HUB
communication (x1)
RJ45 Ethernet port (x1)
Non-volatile Memory
64Mb (for internal data logs and MATE 3
configuration settings)
Interface Display Liquid Crystal Display (LCD)
Control Keypad
4 Soft Keys
6 Hot Keys
4 Navigation keys
1 Control Wheel with Enter Button
Status Indicators 9 LEDs
Battery (for real-time clock and internal memory) CR2032
Communication Protocol Proprietary OutBack network
Interconnection Cabling Standard Category 5 OutBack proprietary
PC Computer Interface Category 5
Environmental Rating Indoor only
Warranty Standard 5-year
Regulatory Specifications
Table 6 Regulatory Specifications for All Models
Regulatory
Specification
Model
Emissions FCC Class B
Regulatory UL 1741 1st Edition; 2005 Version, CSA 107.1-01,
CE Conformance European EN 55022 Class B
Firmware Revision
This manual applies to MATE3 System Display and Controllers with a firmware version of 002.xxx.xxx
or higher.
