Press the UP or DOWN button,
Press the UP and DOWN buttons
to display "25.0Hz" on the main
display.
(The main display will flicker.)
[Continued from previous page]
Press the SET button to set the data.
The display will change to the output
frequency. The motor will start
rotating in the forward direction and
operate at 50.0Hz.
Stopping operation
Press the STOP button.
The motor will start to decelerate
and will stop.
Stop command
Operating
frequency
setting
Reverse run operation at operating frequency 50Hz
Press the DOWN button to set the
rotation direction to reverse run.
Reverse
run setting
Press the RUN button.
As frequency is already set to
50Hz, the motor will start rotating
in the reverse direction and operate
at 50.0Hz.
Run command
Changing from reverse run to forward run during operation.
Forward
run setting
Press the UP button to set the
rotation direction to forward run.
[Continued to next page]
39
．
SET
STOP
RUN
