104 EVO Installation Guide
Appendix B: Contact ID Report Code List
CID# Reporting Code
Prog.
Value
CID# Reporting Code
Prog.
Value
CID# Reporting Code
Prog.
Value
MEDICAL ALARMS - 100 202 Low CO2 34 374 Exit Error Alarm 69
100 Medical Alarm 01 203 Gate Valve Sensor 35 375 Panic Zone Trouble 6A
101 Personal Emergency 02 204 Low Water Level 36 376 Hold-up Zone Trouble 6B
102 Fail to Report In 03 205 Pump Activated 37 377 Swinger Trouble 6C
FIRE ALARMS - 110 206 Pump Failure 38 378 Cross-Zone Trouble 6D
110 Fire Alarm 04 SYSTEM TROUBLES - 300 & 310 SENSOR TROUBLES - 380
111 Smoke 05 300 System Trouble 39 380 Sensor Trouble 6E
112 Combustion 06 301 AC Loss 3A 381 Loss of Supervision - RF 6F
113 Water Flow 07 302 Low System Battery 3B 382 Loss of Supervision - RPM 70
114 Heat 08 303 RAM Checksum Bad 3C 383 Sensor Tamper 71
115 Pull Station 09 304 ROM Checksum Bad 3D 384 RF Transmitter Low Battery 72
116 Duct 0A 305 System Reset 3E 385 Smoke Detector Hi Sensitivity 73
117 Flame 0B 306 Panel Program Changed 3F 386 Smoke Detector Low Sensitivity 74
118 Near Alarm 0C 307 Self-Test Failure 40 387 Intrusion Detector Hi Sensitivity 75
PANIC ALARMS - 120 308 System Shutdown 41 388 Intrusion Detector Low Sensitivity 76
120 Panic Alarm 0D 309 Battery Test Failure 42 389 Sensor Self-Test Failure 77
121 Duress 0E 310 Ground Fault 43 391 Sensor Watch Trouble 78
122 Silent 0F 311 Battery Missing/Dead 44 392 Drift Compensation Error 79
123 Audible 10 312 Power Supply Over Current 45 393 Maintenance Alert 7A
124 Duress-Access Granted 11 313 Engineer Reset 46 OPEN/CLOSE - 400
125 Duress-Egress Granted 12 SOUNDER/RELAY TROUBLES - 320 400 Open/Close 7B
BURGLAR ALARMS - 130 320 Sounder Relay 47 401 Open/Close by User 7C
130 Burglary 13 321 Bell 1 48 402 Group Open/Close 7D
131 Perimeter 14 322 Bell 2 49 403 Automatic Open/Close 7E
132 Interior 15 323 Alarm Relay 4A 406 Cancel 7F
133 24-Hour 16 324 Trouble Relay 4B 407 Remote Arm/Disarm 80
134 Entry/Exit 17 325 Reversing Relay 4C 408 Quick Arm 81
135 Day/Night 18 326 Notification Appliance chk. #3 4D 409 Keyswitch Open/Close 82
136 Outdoor 19 327 Notification Appliance chk. #4 4E REMOTE ACCESS - 410
137 Tamper 1A SYSTEM PERIPHERAL TROUBLES - 330 & 340 411 Callback Request Made 83
138 Near Alarm 1B 330 System Peripheral 4F 412 Successful - Download Access 84
139 Intrusion Verifier 1C 331 Polling Loop Open 50 413 Unsuccessful Access 85
GENERAL ALARMS - 140 332 Polling Loop Short 51 414 System Shutdown 86
140 General Alarm 1D 333 Expansion Module Failure 52 415 Dialer Shutdown 87
141 Polling Loop Open 1E 334 Repeater Failure 53 416 Successful Upload 88
142 Polling Loop Short 1F 335 Local Printer Paper Out 54 ACCESS CONTROL - 420
143 Expansion Module Failure 20 336 Local Printer Failure 55 421 Access Denied 89
144 Sensor Tamper 21 337 Exp. Module DC Low 56 422 Access Report By User 8A
145 Expansion Module Tamper 22 338 Exp. Module Low Batt 57 423 Forced Access 8B
146 Silent Burglary 23 339 Exp. Module Reset 58 424 Egress Denied 8C
147 Sensor Supervision Failure 24 341 Exp. Module Tamper 59 425 Egress Granted 8D
24-HOUR NON-BURGLARY - 150 & 160 342 Exp. Module AC Lost 5A 426 Access Door Propped Open 8E
150 24-Hour Non-Burglary 25 343 Exp. Module Self-Test Fail 5B 427
Access Point Door Status Monitor
trouble
8F
151 Gas Detected 26 344 RF Receiver Jam Detected 5C 428 Access Point Request to Exit 90
152 Refrigeration 27 COMMUNICATION TROUBLES - 350 & 360 429 Access Program Mode Entry 91
153 Loss of Heat 28 350 Communication 5D 430 Access Program Mode Exit 92
154 Water Leakage 29 351 Telco Fault 1 5E 431 Access Threat Level Change 93
155 Foil Break 2A 352 Telco Fault 2 5F 432 Access Relay/Trigger Fail 94
156 Day Trouble 2B 353 Long Range Radio 60 433 Access RTE Shunt 95
157 Low Bottled Gas Level 2C 354 Fail to Communicate 61 434 Access DSM Shunt 96
158 High Temperature 2D 355 Loss of Radio Supervision 62 441 Armed Stay 97
159 Low Temperature 2E 356 Loss of Central Polling 63 442 Keyswitch Armed Stay 98
161 Loss of Air Flow 2F 357 Long Range Radio VSWR problem 64 SPECIAL TROUBLES - 450 & 460
162 Carbon Monoxide Detected 30 PROTECTION LOOP TROUBLES - 370 450 Exception Open/Close 99
163 Tank Level 31 370 Protection Loop 65 451 Early Open/Close 9A
FIRE SUPERVISORY - 200 & 210 371 Protection Loop Open 66 452 Late Open/Close 9B
