120 EVO Installation Guide
Programmable Output Options
C.0.69 PGM State
SECTION [011] OPTION [1]
The PGM is limited to 50mA.
Option [5] OFF = PGM is Normally Open (default).
Option [5] ON = PGM is Normally Closed.
C.0.70 PGM Activation Event
SECTION [014] to [017]
Enter the sections that correspond to the EVENT GROUP, FEATURE GROUP, START # and END # of the PGM and enter
the required data.
C.0.71 PGM Deactivation Event
SECTION [018] to [021]
If the PGM Deactivation Option is set to follow the PGM Deactivation Event, the PGM will return to its normal
state when the event programmed in sections [018] to [021] occurs. Enter the sections that correspond to the
EVENT GROUP, FEATURE GROUP, START # and END # of the PGM and enter the required data.
C.0.72 PGM Deactivation Mode
SECTION [011] Option [2]
Option [2] OFF = Deactivation as per PGM Deactivation Event (default).
Option [2] ON = PGM will deactivate according to the PGM Timer.
C.0.73 PGM Base Time
SECTION [011] Option [3]
Option [3] OFF = PGM Base Time is 1 second (default).
Option [3] ON = PGM Base Time is 1 minute.
C.0.74 PGM Timer
SECTION [013]
To program the timer, enter a 3-digit decimal value (001 to 255) in section [013].
C.0.75 PGM Test
SECTION [030]
Use this section to initiate a PGM test, which will activate the PGM for 8 seconds. Enter section [030] to activate
this test.
Event group Feature group Start # End #
PGM
[014] [015] [016] [017]
Event group Feature group Start # End #
PGM
[018] [019] [020] [021]
