Keyswitch Programming 6
6.1 Keyswitch Numbering
SECTIONS [0501] TO [0532]
Keyswitch Numbering allows you to assign any hardwired input in the system to any of the 32 keyswitch zones
in the control panel (see
Figure 15). UL Note: Do not use Keyswitches in UL Listed systems.
Figure 15: Example of Keyswitch Numbering
6.2 Keyswitch Definitions
Keyswitch Definitions determine how a keyswitch is used.
6.2.1 Keyswitch Disabled
SECTIONS [0601] TO [0632]: FIRST DIGIT = 0
Disables keyswitch input.
6.2.2 Momentary Keyswitch
SECTIONS [0601] TO [0632]: FIRST DIGIT = 1
To arm or disarm a partition using the Momentary Keyswitch, turn on the keyswitch for three seconds then turn
it off.
6.2.3 Maintained Keyswitch
SECTIONS [0601] TO [0632]: FIRST DIGIT = 2
To arm a partition using the Maintained Keyswitch, turn the switch from the ON to the OFF position. Disarm it by
setting the key on the
ON position.
6.2.4 Generates a Utility Key Event on Open
SECTIONS [0601] TO [0632]: FIRST DIGIT = 3
To program a keyswitch to generate a Utility Key Event:
1. Program the Activation Event of a PGM output with the Utility Key Event corresponding to the desired
keyswitch (see PGM Programming Table in the "EVO Programming Guide": Event Group 048).
2. Enable option [3] in the section corresponding to the desired keyswitch.
Control Panel
SN#: 020000A2
Keyswitch B
Keyswitch C
Keyswitch
Zone # Section Serial# Input#
Keyswitch A: 1 = [0501] 020000A2 001
Keyswitch B: 2 = [0502] 34000041 002
Keyswitch C: 3 = [0503] 34000041 006
Input 2
Input 6
Keyswitch A
Input 1
Input Terminals
1 2 3 4 5 6 7 8
C OMMUNICATION N ETWORK
Zone Expansion Module
SN#: 34000041
Input Terminals
1 2 3 4 5 6 7 8
Comb
