18 EVO Installation Guide
Note:For connection of self-contained bell/siren, see Figure 7 on page 22.
When the bell output is not used, the “Bell Absent” message appears in the Trouble Display. To avoid
this, connect a 1k
Ω
resistor across the bell output. UL Note: The keypads must be programmed to beep
with all troubles.
The metal housing which enclosed the Fire and Burglary system housing has knockouts on the sides and in the
back enclosure and shall accommodate conduit of the trade size according to NEC.
WARNING: “To prevent risk of electric shock, disconnect AC battery and phone cord BEFORE Servicing”.
2.14 False Alarm Reduction
In an effort to deter false alarms, the EVO192 provides various programmable features, including the following
programmable features:
• double knockout, cross zoning
• auto zone shutdown
• auto trouble shutdown
• intellizone
• Audible /visual entry/exit delays
• fire alarm verification
• dialer delay before an alarm transmission
• cancel report option
• exit termination zone
2.15 Programmable Outputs
PGM1 to PGM4 are 100mA (max.) solid-state relays with +/- trigger. PGM5 is a 5A/28Vdc N.O./ N.C. relay output.
They can be set at either normally open or normally closed. If the current draw on PGM1 to PGM4 is to exceed
the current output.
2.16 Keyswitch Connections
Connect the keyswitches to the keypad, control panel, or Zone Expansion Module's hardwired input terminals
as shown in
Figure 6.
