84 EVO Installation Guide
Programmable Outputs 13
The control panel provides a maximum of 100 mA to PGM1 to PGM4. PGM5 is a 5A/28Vdc N.O./ N.C. relay
output. Activating a PGM changes it’s state from open to closed or closed to open. Refer to
see section 2.15 on
page 18.
13.1 PGM Activation Event
The PGM Activation Event determines which event will activate the PGM. The Event Group specifies the event,
the Feature Group identifies the source, and the Start # and End # sets the range within the Feature Group (see
PGM Programming Table in the "EVO Programming Guide").
Enter the sections that correspond to the Event Group, Feature Group, Start # and End # of the desired PGM and
enter the desired 3-digit number from the PGM Programming Table:
13.2 PGM Deactivation Option
Once the PGMs are activated, they can deactivate when another event occurs or after a period of time. Enter
the section that corresponds to the desired PGM and enable or disable option
[1] (default = PGM Deactivation
Event):
13.3 Flexible PGM Deactivation Option
The PGM Deactivation Option must be set to PGM Timer for this feature to function. The Flexible PGM
Deactivation Option uses both the PGM Deactivation Event and the PGM Timer. When enabled, and if the PGM
is activated, it will deactivate when either the PGM Deactivation Event occurs or the PGM Timer elapses,
whichever happens first.
Enter the section corresponding to the PGM and enable option [3]
(default = disabled):
Event Group Feature Group Start # End #
PGM 1:
[0910] [0911] [0912] [0913]
PGM 2:
[0920] [0921] [0922] [0923]
PGM 3:
[0930] [0931] [0932] [0933]
PGM 4:
[0940] [0941] [0942] [0943]
PGM 5:
[0950] [0951] [0952] [0953]
PGM 1: [0919]
Optio
n
Feature
PGM 2: [0929]
[1]
ON PGM Timer
PGM 3: [0939]
[1]
OFF PGM Deactivation Event
PGM 4: [0949]
[4]
ON Normally Closed
PGM 5: [0959]
[4]
OFF Normally Open
PGM 1: [0919] PGM 2: [0929] PGM 3: [0939]
PGM 4: [0949] PGM 5: [0959]
