Paradox EVO192 - Page 83

To Next Page

To Previous Page

EVO Installation Guide 83

Ring

Counter

Set the number of rings the VDMP3 will wait before the call

is answered.

[3051]

000 to 008 rings (default 008)

Note: Changing these values will also affect PC

communication via WinLoad software.
