EVO Installation Guide 21
Figure 4 – Sample Power Requirement Calculations
Do not use the same transformer for the control panel and the external power supplies. Do not install
modules more than 914m (3000ft) from the control panel.
2.18 Keypad Zone Connections
Every keypad, except Grafica, has one hardwire input terminal.
Power required by devices connected to control
panel’s
Control Panel
aux. output
61m 15m
APR-PRT3
K641
7.5m (25ft)
15m
DGP2-70
7.5m
APR-ZX8
30m (100ft)
22 AWG
K641
15m
K641
91m (300ft)
290m
DGP2-60
305m (1000ft)
As indicated in
Table 2 on page 20,
this run of wire can
support 700mA. Total
mA on this run of wire:
As indicated in
Table 2 on page 20,
this run of wire can
support 454mA.
Total mA on this run
As indicated in
Table 2 on page 20,
this run of wire can
support 136mA.
Total mA on this run
