EVO Installation Guide 89
14.6 Battery Charge Current
SECTION [3030]: OPTION [5]
Depending on the battery’s capacity, enable or disable the option:
A 40VA transformer is required when selecting the 850mA battery charge current, a 20VA transformer
may damage the system.
14.7 Combus Speed
SECTION [3030]: OPTION [8]
In large installations, set the speed to High. If you are experiencing communication troubles, set the speed to
Normal or install a Hub (APR3-HUB2). The control panel will restart when a change is made
Please note that when the combus speed is changed the following will occur and is considered normal operation:
• The message COMM. TROUBLE CALL SERVICE will be displayed on keypads connected to the combus.
• The AC and STATUS LEDs will begin to alternately flash and all operations on the system will be suspended for approximately one
minute while the system reconfigures.
14.8 Transmit Zone Status on Serial Port
SECTION [3035]: OPTION [7]
When enabled, the control panel will transmit zone status information through the serial port. Use this when
there are devices or software connected to the serial port like WinLoad.
14.9 Serial Port Baud Rate
SECTION [3035]: OPTION [8]
Adjust depending on the baud rate set in WinLoad or NEware:
If communication between the control panel and the computer is experiencing difficulty at 57,600 baud, especially over long distances
reduce the baud rate of the software to 38,400 baud.
14.10 Partitioning
SECTION [3031]: OPTIONS [1] TO [8]
(default = partition 1 enabled) The control panel can provide up to eight completely independent partitions.
Most features and options can be independently set for each partition. All zones, keyswitch zones, user codes
and system modules are assigned to specific partitions. The EVO48 only has 4 partitions.
14.10.1 Panel Partition Assignment
SECTION [3020]
(default = 00) The control panel will report system events as originating from one or all enabled partitions. The
System Troubles can only be viewed through the partitions enabled in this section. Enter a 2-digit decimal
number from 01 to 08 which represent partitions 1 to 8. Enter 00 to disable this feature.
[5]
ON 850mA
[5]
OFF 350mA (default)
[8]
ON High Speed
[8]
OFF Normal Speed (default)
[8]
ON 57,600 baud
[8]
OFF 38,400 baud (default)
[1]
Partition 1
[3]
Partition 3
[5]
Partition 5
[7]
Partition 7
[2]
Partition 2
[4]
Partition 4
[6]
Partition 6
[8]
Partition 8
