32 EVO Installation Guide
4.1 Zone Programming
Two different methods can be used to program zones:
4.1.1 Using section [0400]
Allows you to program zones 001 through 192 as shown in the diagram.
In any Zone Programming option, pressing [ACC] will save the data and go to the next zone on the same
option screen. Pressing [TRBL] will save the data and go to the previous zone on the same option screen.
4.1.2 Using zone serial and input numbers
If you are not using an K641 or an K641R keypad, you can only program zones 1 to 96 through sections [0001]
to [0096].
4.2 Zone Numbering
SECTION [0400]
S
ECTIONS [0001] TO [0096]
• To assign an addressable PIR or door contact to the combus, program the module’s serial number into the
section corresponding to the zone.
• To assign a detection device connected to a module or control panel's hardwired input terminal, program the
module's or control panel's serial number and the input number to the desired zone. See the “Digiplex
Modules Programming Guide” for details of its input numbers (input numbers not required for keypad
zones).
If PGM1 is defined as a smoke detector input, the control panel will recognize it as input # 255.
4.2.1 Clearing a Zone’s Numbering
Using section [0400]
1. Enter the zone number you wish to delete.
2. Press [0] all the way through the serial/input, parameters and report codes screen.
3. Press [
ENTER] to exit.
Using an LCD Keypad:
1. Enter a section number between [0001] to [0096].
2. Press [0] and then [
ENTER] to save and exit.
Using a Grafica Keypad:
1. Enter a section number between [0001] to [0096].
2. Press [0] to clear the serial number.
3. Highlight the input number and then press [0] to clear the data.
Zone
Number
Zone
Numbering
Zone
definitions
Zone Partition
Assignment
Zone Options
1 [0001] [0101] [0201] [0301]
2 [0002] [0102] [0202] [0302]
+1 per zone +1 per zone +1 per zone +1 per zone
96 [0096] [0196] [0296] [0396]
