EVO Installation Guide 29
3.3 Programming Through BabyWare
It is recommended that system and module programming be done through BabyWare.
3.4 Programming Through a Keypad
Use the “EVO Programming Guide” to record how the sections were programmed. To enter programming
mode:
For LCD Keypads: The control panel will save the data and go to the next section or press the [ENTER] key to
save the data and go to the next section. Press the
[CLEAR] key go to the preceding step or to erase the current
data entry.
For Grafica Keypads: Press Grafica’s center action key (Save) to save the data and go to the next section. Press
the right action key (Exit) to go to the preceding step or press the left action key (Clear) to erase the current
data.
3.4.1 Feature Select Programming
Most of the options are programmed using the Feature Select Method.
For LCD Keypads: The option is considered ON when the number appears within the brackets on the LCD
keypad. Turn options ON and OFF by pressing the corresponding keys on the keypad and then press
[ENTER] to
save.
For Grafica Keypads: Select or clear the check boxes or set the options by pressing the corresponding keys on
the keypad. The feature is considered ON when its check box is selected. Press the Grafica’s center action key
(Save) to save.
3.4.2 Decimal Programming
Sections may require 3-digit decimal values from 000 to 255.
3.4.3 Hexadecimal Programming
Sections may require Hexadecimal values from 0 to F. Press:
For LCD Keypads:
[0] to [9] = values 0 to 9 respectively
[
STAY] key = A [DISARM] key = D
[
FORCE] key = B [BYP] key = E
[
ARM] key = C [MEM] key = F
For Grafica Keypads:
[0] to [9] = values 0 to 9 respectively
[#] = A to F (press the key until the desired letter appears)
1. Press and hold the [0] key.
2. Key in the
[INSTALLER CODE] (default = 000000).
3. Key in the 4-digit
[SECTION].
4. Key in required [DATA]. Refer to the “EVO Programming
Guide” or to the corresponding sections in this
manual.
