13.4 PGM Deactivation Event
The PGM Deactivation Event determines which event will return the PGM to its original state. The Event Group
specifies the event, the Feature Group identifies the source, and the Start # and End # determine the range
within the Feature Group.
Enter the sections that correspond to the Event Group, Feature Group, Start # and End # of the desired PGM and
enter the desired 3-digit number from the PGM Programming Table.
13.5 PGM Timer
When the PGM Deactivation Option is enabled, the PGM Timer determines how many seconds or minutes the
PGM remains activated.
Enter the section that corresponds to the desired PGM and enter a value from 001 to 255 (default = 005). The
value entered is either in seconds or minutes as determined by the PGM Time Base Selection:
13.5.1 PGM Time Base Selection
The PGM Time Base Selection determines whether the PGM Timers are in minutes or seconds (default =
seconds):
13.6 PGM1 Becomes a 2-wire Smoke Detector Input*
SECTION [3030]: OPTION [1]
(default = disabled) When enabled, PGM1 acts as a zone input for two-wire smoke detectors. When
programming Zone Numbering the control panel will recognize PGM1 as input number 255.
* UL Note: Not verified by UL.
13.7 PGM Test Mode
Entering sections [0901] to [0903] activates the corresponding PGM for 8 seconds to verify if the PGM is
functioning as desired.
Event Group Feature Group Start # End #
PGM 1:
[0914] [0915] [0916] [0917]
PGM 2:
[0924] [0925] [0926] [0927]
PGM 3:
[0934] [0935] [0936] [0937]
PGM 4
[0944] [0945] [0946] [0947]
PGM 5
[0954] [0955] [0956] [0957]
PGM 1: [0918] PGM 2: [0928] PGM 3: [0938]
PGM 4: [0948] PGM 5: [0958]
PGM 1: [0919]
Optio
n
Feature
PGM 2: [0929]
[2]
ON Minutes
PGM 3: [0939]
[2]
OFF Seconds
PGM 4: [0949]
PGM 5: [0959]
PGM 1: [0901] PGM 2: [0902] PGM 3: [0903]
PGM 4: [0904] PGM 5: [0905]
