100 EVO Installation Guide
15.6 Partition Assignment
SECTIONS [1002] TO [1999]: ASSIGN AREA SCREEN, OPTIONS [1] TO [8]
Each of the 998 user access codes can be assigned to one or more partitions. Users can only arm, disarm and
view the status of the partitions assigned to their user access codes. Select one or more of the partitions for
each user access code as shown in
Figure 21 on page 99.
If no partition assignment is selected, the user access code will only be able to activate PGMs.
The default setting depends on the programming user’s assigned partitions. For example, when a user (with master feature) that is
assigned to partitions 1 and 2 programs a user code, partitions 1 and 2 will be the default setting for the new user.
[1] [2]
OFF OFF Master disabled
User cannot create or modify other user access
codes.
ON OFF Master enabled
User can create new user access codes with
default options only, can program PINs and User
Labels.
ON ON
Full Master
enabled
User can create and modify user access codes and
program the User Options, Partition Assignment
(can assign only the partitions the Master Code
has access to), Access Control features, PINs and
User Labels.
[3]
Duress
A Duress enabled user access code can arm or
disarm the partition and can immediately
transmit a silent alarm to the monitoring station.
[4]
Bypass User can program bypass entries.
[5]
Arm Only
User can arm assigned partitions, but cannot
disarm.
[6]
Stay or Instant
Arm
User can Stay arm or Instant arm assigned
partitions.
[7]
Force Arm User can Force arm assigned partitions
[8]
User Menu
Access
Option [8] ON = User can access all its assigned
partitions, regardless of the keypad’s partition
assignment.
Option [8] OFF = User can only access the
partitions assigned to both itself and the keypad.
To Next Page
