EVO Installation Guide 45
Testing and Maintenance 7
7.0.1 EVO192 Panel
The Digiplex EVO is a security and access control system with 8 on-board zone inputs (16 with zone doubling)
that is expandable to 48 or 192 zones via the 4-wire combus. The EVO control panel features up to 999 users, 8
partitions, 32 doors and can support up to 254 modules in any combination.
The Digiplex EVO system provides the highest level of protection for banks, high-security military and
government sites, luxurious residential homes and any place where maximum security is essential. These
systems are designed to be easy to use, and the modular concept of these systems provides installers with
labour-saving features that make expanding, installing and servicing these systems quick and convenient.
Expand the EVO system by adding plug-and-play expansion modules anywhere and in any combination on the
4-wire combus. Modules are connected to the combus at the most convenient location and then their zone
inputs are assigned to the desired zone and partition. Also, only a module’s used inputs are assigned to zones in
the system. Keyswitches, remote controls and unused module inputs do not use up zones. Once installed, all
combus modules, including motion detectors, can be programmed remotely via a keypad or the WinLoad
upload/download software.
EVO also supports 32 virtual zones in addition to its security zones and access control doors. Virtual zones can
be used to automate PGM activations without occupying a security zone and without affecting the system’s
security functions. The EVO system is a logical solution to every installer’s security, access control and home
automation installation needs.
Features of EVO192 Controller
• Digital combus:
• Provides constant power, supervision and two-way communication between the control panel and all its
modules
• Supports up to 127 modules
• Connect modules up to 914m (3000ft) from the panel2
• Sabotage-proof technology without additional wiring
• 8 on-board zones (16 w/ zone doubling) expandable to 192 zones via 4-wire combus
• Automatic Daylight Saving Time feature
• 2 on-board solid-state relays PGM outputs (+ 3 optional), negative or positive triggering
• PGM1 can be used as a 2-wire smoke input3
• Built-in-real-time clock backup battery
• 1 supervised bell output, auxiliary output and telephone line
• Push button software reset (reset to default values and restart)
• Push button to activate or deactivate the Auxiliary output
Note: Connection of non ETL/UL listed component will void the ETL listing
Note: Connect according to the wiring requirements described in the Wiring Diagram
Note: 2-Wire Smoke Detector was not evaluated by ETL
• Fits in a 28cm x 28cm x 7.6cm (11in x 11in x 3in) metal box
• 5 on-board solid-state PGM outputs, negative or positive triggering
