46 EVO Installation Guide
• Supports up to 254 expansion bus modules
• 999 user codes
• 8 partitions
• 2048 events buffered
Specifications
Control Panel
AC Power: 17Vac, 40VA, 60Hz
Battery: 12Vdc, 7Ah
Auxiliary Power: 11.4 to 12.5Vdc, 700mA maximum, fuseless shutdown at 1.1A
Bell Output: 11.4 to 12.5Vdc, 1A maximum, fuseless shutdown @ 3A
PGM Output: PGM1 to PGM4 100mA solid-state relays with +/- trigger, PGM5 Form C relay output rated at 5A/28Vdc N.O. / N.C.
Max current/Power 40VA
Operational Temperature: -20°C to +50°C (4°F to +122°F)
All control panel outputs are rated to operate between 11.4Vdc and 12.5Vdc
Electrical ratings (current, power) on the product or in the installation instructions. Missing Current / Power
Specifications may change without prior notice.
See Component Installation guides at the end of this document for Installation instructions.
7.0.2 Hub Module HUB2
The APR3-HUB2 is a non-addressable module that extends and divides the control panel’s bus into two
completely isolated bus outputs (two for each connected APR3-HUB2). It extends the combus/communication
bus by regenerating the signal between the control panel and its modules. Should one bus output experience
trouble or tampering, the other will remain unaffected. The hub monitors the signal between the control panel
and modules on each output. If the hub detects a loss of signal integrity it will cut off the troubled output until
proper communication is reestablished.
See Component Specifications and Installation guides at the end of this document for Installation instructions.
7.0.3 Hardwired keypad K641
The K641 Keypad allows you to control your Paradox system’s functions through its keypad interface.
General Note 1
Please note that only LCD and Grafica keypads can be used to program the EVO
system. LED keypads cannot be used to program the system.
General Note 2
Please note that the steps may differ when programming with the Grafica
keypad (DNE-K07). If not indicated, refer to the complete “Grafica User Manual”,
which can be downloaded for free from our website at paradox.com
