36 EVO Installation Guide
4.6.2 Bypass Zones
SECTION [0400]: OPTION [2]
S
ECTIONS [0101] TO [0196]: OPTION [2]
(default = enabled) Allow zones to be Manually Bypassed.
4.6.3 Stay Zones
SECTION [0400]: OPTION [3]
S
ECTIONS [0101] TO [0196]: OPTION [3]
Only zones with option [3] enabled will be bypassed when the partition is Stay armed or Instant armed. All
other zones will remain activated. Fire Zones cannot be set as Stay Zones.
4.6.4 Force Zones (Not to be used with UL Listed systems)
SECTION [0400]: OPTION [4]
S
ECTIONS [0101] TO [0196]: OPTION [4]
Only zones with option [4] enabled can be bypassed when the partition is Force armed. Fire Zones cannot be
Force Zones.
4.6.5 Alarm Types
SECTION [0400]: OPTION [2] & [6]
S
ECTIONS [0101] TO [0196]: OPTIONS [5] & [6]
4.6.6 Intellizone*
SECTION [0400]: OPTION [7]
S
ECTIONS [0101] TO [0196]: OPTION [7]
(default = 032) If an alarm condition occurs on a zone with option [7] enabled, the control panel triggers the
Intellizone Delay. Fire Zones cannot be set as Intellizones. An alarm will only be generated if the selected
conditions occur during the Intellizone Delay:
1. An alarm occurs on another zone defined as Intellizone.
2. The zone in alarm restores and reoccurs.
3. The zone stays in alarm for the entire Intellizone Delay.
Key in the desired 3-digit delay value (010 to 255 seconds, default value is 32 seconds) into the section
corresponding to the desired partition
Partition 1: [3114] Partition 5: [3514]
Partition 2: [3214] Partition 6: [3614]
Partition 3: [3314] Partition 7: [3714]
Partition 4: [3414] Partition 8: [3814]
Option
Feature Description
[5] [6]
OFF OFF Steady Alarm sends the report code and activates the bell output
ON OFF Pulsed Alarm
sends the report code and pulses the bell output
(see Figure 14)
OFF ON Silent Alarm
sends the report code, but the bell
output is not activated. Partition must
be disarmed.
ON ON Report Only sends the report code. Disarming is not required.
