40 EVO Installation Guide
Remote Control Programming 5
5.1 Hardware Requirements
5.2 Remote Control Template
It is possible to set up to 16 different button templates which can then be assigned to individual users. Each
user is pre-programmed with a default remote control button pattern: (1 B) (C 0) (template 1).
If the EVO48 System Includes:
MG-RTX3 Wireless Expansion Module And K641 / K641R keypad
Up to 96 remote controls can now be programmed into the EVO control
panel and configured using a master code or installer code.
If the EVO192 System Includes:
MG-RTX3 Wireless Expansion Module And K641 / K641R keypad
Up to 999 remote controls can now be programmed into the EVO control
panel and configured using a master code or installer code.
If the System Includes:
MG-RTX3 Wireless Expansion Module But does not include:K641 /
K641R keypad. Remote controls must be stored in the wireless
expansion module (32 remotes per MG-RTX3) by enabling option [1]
in section [3029].
Section Option Description
[2940]
Default button
Template
To select a button template as
the default template, enter (00)
to (15) representing button
templates in sections [2900] to
[2915].
[2941]
Assign Button
Template
To assign a button template to a
user, select user when
prompted, then enter (00) to
(15) representing button
templates in sections [2900] to
[2915].
Section Template # Button Options
[2900] Template 1 (__/__) (__/__)
[2901] Template 2 (__/__) (__/__)
[2902] Template 3 (__/__) (__/__)
[2903] Template 4 (__/__) (__/__)
[2904] Template 5 (__/__) (__/__)
[2905] Template 6 (__/__) (__/__)
