74 EVO Installation Guide
* UL Note: Installer must verify the compatibility with of the DACR. Use listed compatible DACRs.
10.7.1 Standard Pulse Formats
The control panel can use the Ademco slow, Silent Knight fast and Sescoa standard pulse reporting formats
(see Table 6).
10.7.2 Ademco Express
The Ademco Express is a high-speed reporting format that communicates 2-digit (00 to FF) report codes. The
Ademco Express does not use the Contact ID Report Codes.
10.7.3 Contact ID Pager
The control panel will transmit a Contact ID report instead of a user generated numerical code to a pager. The
Contact ID report code will come from either the Automatic Report Code List
on page 101 or the Contact ID
Report Code List on page 104.
10.7.4 Ademco Contact ID
Ademco Contact ID is a fast communicator format that uses tone reporting. To program the report codes, use
the 2-digit hexadecimal values from the Contact ID Report Codes List in the “EVO Programming Guide”. Enter
00 to disable reporting or FF to use the default report code from the Automatic Report Code List in the “EVO
Programming Guide”. To program a set of default Contact ID codes, refer to
see section 10.17 on page 77.
10.7.5 SIA FSK
SIA FSK is a fast communicator format that uses tone reporting. To program the report codes, enter 00 to
disable reporting or any other value to use the default report code from the Automatic Report Code List in
the “EVO Programming Guide”. To program a set of default SIA FSK codes, refer to
Auto Report Code
Programming on page 77.
10.7.6 Pager Reporting Format
Using this format allows the control panel to transmit report codes to a pager. A pound symbol “#” is
automatically generated after the report code.
10.8 Event Call Direction
Event groups can be programmed to dial up to four monitoring station telephone numbers with one used as a
backup. The numbers are dialed sequentially, skipping any disabled numbers and stopping once all selected
telephone numbers have been reached. If the control panel still fails to report to a monitoring station
telephone number after reaching the Maximum Dialing Attempts
(see section 10.8.1 on page 75), the control
panel will dial the selected backup telephone number. For each section enable or disable the options:
3 = Ademco Express (DTMF 4+2) 7 = Pager
Troubles and Restore Troubles: [3080]
Special System, Arming, Disarming and Alarm Reporting: [3081]
Access Code and Keyswitch Arming and Disarming
Partition 1: [3127] Partition 3: [3327] Partition 5: [3527] Partition 7: [3727]
Partition 2: [3227] Partition 4: [3427] Partition 6: [3627] Partition 8: [3827]
Zone Alarms and Alarm Restores
Partition 1: [3128] Partition 3: [3328] Partition 5: [3528] Partition 7: [3728]
Partition 2: [3228] Partition 4: [3428] Partition 6: [3628] Partition 8: [3828]
Tampers and Tamper Restores
Partition 1: [3129] Partition 3: [3329] Partition 5: [3529] Partition 7: [3729]
To Next Page
