EVO Installation Guide 61
Alarm Options 9
9.1 Bell/alarm Output
(default = only option [1] enabled) When an alarm condition is detected in a partition, the control panel can
trigger the on-board
BELL output enabling any bells or sirens connected to it. In section [3032] enable the option
to enable the bell output in the desired partition (off = disabled):
9.2 Bell Cut-off Timer
(default = 004) After an audible alarm, the bell or siren will stop once the partition is disarmed or when the Bell
Cut-Off Timer has elapsed. Enter any value between 001 and 255 minutes:
9.2.1 No Bell Cut-Off on Fire Alarm
SECTION [3030]: OPTION [2]
(default = disabled) The control panel can disable the Bell Cut-Off Timers when alarms are generated from
zones defined as Standard or Delayed Fire Zones
(see section 4.4 on page 33). The BELL output will remain
enabled until a user disarms the partition in alarm.
9.2.2 Recycle Alarm Rate
(default = 000) The control panel re-verifies the zone status during an alarm at a programmed rate once the Bell
Cut-Off Timer and the Recycle Delay elapse. If open zones remain, the control panel will regenerate the alarm.
Enter the number of times from 001 to 255 (000 = no limit) in one armed period that the control panel will re-
verify the zone status:
9.2.3 Recycle Delay
(default = 000) The Recycle Delay is the amount of time the control panel will wait after the Bell Cut-off occurs
before re-verifying the zone status. Program the Recycle Delay from 001 to 255 minutes (000 = disabled):
9.3 Wireless Transmitter Supervision Options
SECTION [3034]: OPTIONS [1] AND [2]
When the control panel detects a Supervision Loss, the control panel can generate an alarm and/or trouble,
unless the Wireless Transmitter Supervision Option is disabled.
The Supervision feature must be enabled in the Magellan Wireless System (MG-RTX3) for this feature to function.
Partition 1: Option [1] Partition 5: Option [5]
Partition 2: Option [2] Partition 6: Option [6]
Partition 3: Option [3] Partition 7: Option [7]
Partition 4: Option [4] Partition 8: Option [8]
Partition 1: [3113] Partition 3: [3313] Partition 5: [3513] Partition 7: [3713]
Partition 2: [3213] Partition 4: [3413] Partition 6: [3613] Partition 8: [3813]
Partition 1: [3117] Partition 3: [3317] Partition 5: [3517] Partition 7: [3717]
Partition 2: [3217] Partition 4: [3417] Partition 6: [3617] Partition 8: [3817]
Partition 1: [3116] Partition 3: [3316] Partition 5: [3516] Partition 7: [3716]
Partition 2: [3216] Partition 4: [3416] Partition 6: [3616] Partition 8: [3816]
