EVO Installation Guide 127
Receiving center phone number: 999-999-999
Call waiting cancelation code: *70
Phone number to program: *70P999999999
4
When the test initiates or terminates, the communicators (PSTN/GSM, LAN and GPRS) will report the test initiation/termination to the monitoring
station. Automatic Termination of System Test Mode is not supported.
• Cross zones have the ability to individually protect the intended area (e.g., motion detectors, which overlap).
• Cross zoning is not recommended for line security Installations nor is it to be implemented on exit / entry zones.
• There is a communicator delay of 30 seconds in this control panel. It can be removed, or it can be increased up to 45 seconds at the option of the
end user by consulting with the Installer.
• Do not duplicate any reporting codes. This applies for all communication formats other than SIA and Contact ID sending automatic programmed
reporting codes.
• The control unit must be installed with a local sounding device and an off-premise transmission for SIA communication format.
• The control unit must be installed with a local sounding device and an off-premise transmission for SIA communication format.K641/K641+/
TM50 Must be in the Installation guides
1. Add a note, in the LCD manual, near the mute programming statement: “Mute shall be disabled to comply
with CP-01 standards.”
2. Support new error messages :
a. No alarm was reported
b. Cancel alarm event reported
EVO192 BOARD LABELLING
3. VP27 Labeling (Ref. 4.4.2) Add a sticker on the main connector to indicate the operating voltage of the
panel.
The panel will cease to process sensor trips if the voltage is under 8.5V. Rechargeable Battery UL/ULC - 12Vdc /
4Ah or 7Ah
UL Warning: A 12Vdc / 7Ah battery is required to comply with UL fire requirements.
Caution: Disconnect battery before replacing the fuse.
Note: Install
Note: Improper connection of the transformer may result in damage to the system.
4. Specify on the interconnect label, information that allows an installer to confirm compatibility between the
panel zone inputs and the sensors selected for the installation. (ex. Annex J)
Zone Input Specifications:
• Maximum loop current (shorted loop): 2.2 mA
Transformer:
UL: Universal UB1640W 17VAC
40VA
DC Power Supply rated at: 1.7A
Auxiliary Supply can provide a
maximum
typ: 600mA, max: 700mA
Do not exceed 200mA for UL
installation
Acceptable Battery Charge Currents 350mA/700mA
