126 EVO Installation Guide
Appendix G EVO192 CP-01 Installer Programming1
Quick Reference Chart SIA False Alarm Reduction
Minimum requirement system for SIA CP-01 Installations:
• 1 EVO192 CP-01 Control Panel
• 2 Local Annunciation Devices
The local annunciation devices must be of the following keypads.
• K641/TM50
Caution
• For SIA CP-01 installations, only use modules / devices that are listed on this page.
• Fire Alarm Verification feature (Auto Verified Fire zone) is not supported for 2-wire smoke detectors zones. This feature may be enabled for 4-
wire smoke detectors only.
• Call Waiting Cancel feature on a non-Call Waiting line will prevent successful communication to the central station, see note 3 below.
• All smoke detectors on the system must be tested annually by conducting the Installer Walk Test. Please refer to the smoke detector installation
instructions on how to correctly test the detectors.
Notes
1
Programming at installation may be subordinate to other UL requirements for the intended application.
2
Combined Entry Delay and Abort Window should not exceed 1 minute.
3
For “Call Waiting” option. The installer needs to verify the code in the premises area for the telephone network that disables the call waiting
feature, then add it to the monitoring station phone number. For example:
CP-01
Paragraph
This Installation
Manual (IM)
Feature Range
Shipping
default
Recommended
Programming*
4.2.2.1
section 8.18 on page
58
Exit time 45 sec – 255 sec 60 seconds 60 seconds
4.2.2.2
Refer to Keypad(s)
manual
Progress annunciation
Individual keypads may be
disabled
All annunciators
enabled
All annunciators
enabled
4.2.2.3 Not programmable Exit time restart For re-entry during exit delay
Always
Enabled
Cannot be
disabled
4.2.2.5
section 8.13 on page
57
Auto Stay Arm on non-
evacuated Premises
If no exit after full arm Enabled Enabled
4.2.3.1
section 4.4.2 on
page 33
Entry delay(s) 30 sec – 255 sec
2
30 seconds At least 30 sec
2
4.2.5.1
section 4.6.8 on
page 39
Abort Window – for non-fire
zones
May be disabled by zone Enabled Enabled (all zones)
4.2.5.1
section 4.6.8 on
page 39
Abort Window Time – for
non-fire zones
15 sec – 45 sec
2
30 seconds At least 30 sec
2
4.2.5.1.2 Not programmable Abort annunciation
Annunciate that no alarm was
transmitted
Always
Enabled
Cannot be
disabled
4.2.5.4 Not programmable Cancel window No limits No limits No limits
4.2.5.4.1 Not programmable Cancel annunciation
Annunciate that a cancel was
transmitted
Always
Enabled
Cannot be
disabled
4.2.6.1 &
4.2.6.2
section 10.2.10 on
page 70 and section
15.6 on page 100
Duress feature
No 1+derivative of another
user code. No duplicate with
other user codes.
Disabled Disabled
4.3.1
section 4.6.7 on
page 38
Cross zoning Programming needed Disabled
Enabled and two
(or more) zones
programmed
4.3.1
section 4.6.6 on
page 36
Programmable cross zoning May Program 48 sec.
Per walk path in
protected
premises
4.3.2
section 4.6.1 on
page 35
Swinger shutdown
For all non-fire zones,
shutdown at 1 or 2 trips
two trip two trip
4.3.3
section 2.22.3 on
page 25
Fire Alarm Verification Depends on sensors Disabled
Enabled unless
sensors can self-
verify
4.5
section 11.9 on page
79
Call waiting Cancel Depends on user phone line Disabled
Enabled if user has
call waiting
3
4.6.3
section 7.3 on page
48
System test (test report +
walk test mode + siren)
Test periodically. Disabled
Enabled to test all
zones, siren,
communicator
4
