EVO Installation Guide 91
14.13 Module Reset
SECTION [4001]
To reset a module connected to the combus to its default values, key in the module's serial number into section
[4001].
14.14 Locate Module
SECTION [4002]
To locate a specific module on the combus, key in the module's serial number into section [4002]. The LED on the
module flashes until the serial number is entered or the module’s tamper or unlocate switch is pressed.
14.15 Module Programming
SECTION [4003]
To program a module, enter section [4003] to enter Module Programming Mode (see section 3.5 on page 30), and
enter the module's serial number. To exit, press the [CLEAR] key until Normal Mode is displayed.
14.16 Module and Label Broadcast
SECTION [4004]
Module Broadcast
To copy the contents of the programming sections from one module to another, enter the serial number of the
source module in section
[4004], enter the serial numbers of all the destination modules and press [ACC] or the
center action key (Start).
Label Broadcast
Copy the User Labels, Zone Labels (sections [0301] to [0396]), the Door Labels (sections [2301] to [2332]) and
the Partition Labels (sections [3100], [3200], [3300], [3400], [3500], [3600], [3700] and [3800]) to all the
modules in the system that support these labels. To transmit the labels, in section [4004], enter the control
panel’s serial number. From the Destination screen, do not enter a serial number and press
[ACC] if using an LCD
keypad or the center action key (Start) if using a Grafica keypad.
The Module and Label Broadcast feature will only work when a module is broadcasting its data to a
module or to modules of the same type and model number.
14.17 System Date & Time
The System Date and Time is programmed through the User Menu.
14.18 Quick Module Scanning
SECTION [4005]
After entering the section, the control panel will scan all addresses assigned to modules. If any missing modules
are detected (i.e. detector
removed from the combus), the control panel will erase the module's serial number, removing the module from
the control panel's memory.
14.19 Module Scanning
SECTION [4006]
After entering the section, the control panel will scan all addresses on the combus. If any missing modules are
detected (i.e. detector
removed from the combus), the control panel will erase the module's serial number, removing the module from
the control panel's memory.
