4. Press Grafica’s center action key (Save) to save and exit.
4.3 Zone Doubling (ATZ)
SECTION [3033]: OPTION [8]
(default = disabled) Fire Zones cannot be doubled.
4.4 Zone Definitions
4.4.1 Zone Disabled
section [0400]: First digit = 0
SECTIONS [0101] TO [0196]: FIRST DIGIT = 0
Disables the corresponding zone. Zones are disabled by default.
4.4.2 Entry Delays 1 and 2
section [0400]: First digit = 1 and 2
SECTIONS [0101] TO [0196]: FIRST DIGIT = 1 AND 2
(default Entry Delay 1= 030, Entry Delay 2 = 060) A zone defined as Entry Delay 1 follows the Entry Delay 1
Timer of its assigned partition. A zone defined as Entry Delay 2 follows the Entry Delay 2 Timer of its assigned
partition. Each partition includes two Entry Delay Timers. To program an Entry Delay Timer, key in the desired
3-digit delay value (001 to 255 seconds) into the corresponding section.
These are the same timers used for Stay Delay zones.
4.4.3 Follow Zones
section [0400]: First digit = 3
SECTIONS [0101] TO [0196]: FIRST DIGIT = 3
The control panel waits until the end of the Entry Delay before generating an alarm if an Entry Delay zone
opens before the Follow zone.
Input Doubled Zone Input
Input 01 Input 09 (ATZ of Input 01)
Input 02 Input 10 (ATZ of Input 02)
Input 03 Input 11 (ATZ of Input 03)
Input 04 Input 12 (ATZ of Input 04)
Input 05 Input 13 (ATZ of Input 05)
Input 06 Input 14 (ATZ of Input 06)
Input 07 Input 15 (ATZ of Input 07)
Input 08 Input 16 (ATZ of Input 08)
Partition 1
Entry Delay 1 Timer: [3111]
Entry Delay 2 Timer: [3112]
Partition 2
Entry Delay 1 Timer: [3211]
Entry Delay 2 Timer: [3212]
Partition 3
Entry Delay 1 Timer: [3311]
Entry Delay 2 Timer: [3312]
Partition 4
Entry Delay 1 Timer: [3411]
Entry Delay 2 Timer: [3412]
Partition 5
Entry Delay 1 Timer: [3511]
Entry Delay 2 Timer: [3512]
Partition 6
Entry Delay 1 Timer: [3611]
Entry Delay 2 Timer: [3612]
Partition 7
Entry Delay 1 Timer: [3711]
Entry Delay 2 Timer: [3712]
Partition 8
Entry Delay 1 Timer: [3811]
Entry Delay 2 Timer: [3812]
