1. Control Features
Figure 1 is a quick overview of the 500ML Lighting Control Console controls.
Figure 1: 500ML Lighting Control Console Control Features
Masters (Faders)
The 500ML Lighting Control Console consists of multiple master controls, each consisting of a fader and flash, go,
pause/back buttons. Masters are grouped into blocks of four, whereas each group has a LCD screen to display the
current fader’s state.
8-Inch Color TFT Display
On / Off Button
USB 2.0 Ports
Encoders
Multifunction
Wheel
Backlit Command / Programming Keys
Bump Buttons
Faders
Fader Play / Pause /
Reverse Buttons
Status Displays
Bump Buttons
Faders
Fader Play / Pause /
Reverse Buttons
Status Displays
