Working with Effects 99
500ML Lighting Control Console
Operation Guide
"Offset" Effect Attribute
The "Offset" effect attribute shifts the start and end point for each effect, so they can be spread. The effect offset is
assigned in degrees, where 0° means the start and end points are not shifted, whereas 360° means they are shifted by
a full duration of the effect.
Figure 178: Effect Offset Attribute
"Duty Cycle" Effect Attribute
The "Duty Cycle" attribute defines how long the duration of the effect within a cycle is. It is assigned as a percentage.
Note: The "Jump" effect form requires the duty cycle to be smaller than 100% in order to function correctly.
Figure 179: Duty Cycle Effects Attribute
