LIFEPAK 15 Monitor/Defibrillator
Service Manual
Troubleshooting
Troubleshooting Chart
Section Menu Section Contents Back Index
102
5
QUIK-COMBO Patient
Impedance Test
Inappropriate screen message response Verify test setup and retry test.
Check therapy cable; replace if necessary.
Possible W11 Therapy Connector Cable failure.
Possible A04 Therapy PCB failure.
Defibrillation Isolation
Test
Measured energy exceeds 2 joules Verify test setup and retry test.
Possible damaged internal high-voltage wiring.
Possible internal high-voltage wire connection issue.
QUIK-COMBO or Hard
Paddles Synchronous
Cardioversion Test
No Sync mark Verify test setup and retry test.
Adjust ECG size.
Possible A01 System PCB failure.
Failure to transfer coincident with Sync
mark
Take device out of Sync and attempt to discharge.
Possible A10 Main Keypad failure.
Check therapy cables or hard paddles; replace if necessary.
Sync discharge time exceeds 60 ms Verify test setup and retry test.
Possible A01 System PCB failure.
Pacing Test No pacer output Verify test setup and retry test.
Possible A13 Transfer Relay connection problem at P22.
Possible A13 Transfer Relay failure.
Possible A04 Therapy PCB failure.
User Test Service LED illuminates, User Test fails See Processing Service Log Codes (p. 115) for assistance.
Table 5.1— Corrective Actions (Continued)
Area Observed Symptom Suggested Corrective Action
