Audio Test Inaudible or garbled audio Possible W17 Speaker Assembly failure.
Possible A05 Interface PCB failure.
Possible A01 System PCB failure.
Power Source Management
Test
Verify instructions and retry test.
(if available) Verify Aux Power adapter LED is ON and input cable is
connected to device.
Substitute another battery and retry test.
Possible loose or broken battery pin(s).
Possible A03 Power PCB failure.
QUIK-COMBO or
Hard Paddles Delivered
Energy Test
No energy discharge Verify test setup and retry test.
See Processing Service Log Codes (p. 115) for assistance.
Check therapy cable or hard paddles; replace if necessary.
Possible W11 Therapy Connector Cable failure.
Possible A04 Therapy PCB failure.
Possible A22 Biphasic Module PCB failure.
Possible A14 Inductive Resistor failure.
Possible A15 Energy Storage Capacitor failure.
ABNORMAL ENERGY DELIVERY
message appears
Possible A13 Transfer Relay connection problem at P22.
Possible A13 Transfer Relay failure.
Possible A04 Therapy PCB failure.
Delivered energy out of tolerance Perform TCP–Defibrillator Energy Calibration.
Table 5.1— Corrective Actions (Continued)
Area Observed Symptom Suggested Corrective Action
