LIFEPAK 15 Monitor/Defibrillator
Service Manual
Troubleshooting
Therapy Service Codes
Section Menu Section Contents Back Index
131
5
a017 TH_ERROR_DEFIB (Defib. error report)
10
a018 TH_ERROR_PACER (Pacer error report)
15
a01a TH_ERROR_PACER_FAULT (Pacing fault condition occurred [rate(0), current(1), pulse width(2)], limit exceeded; param = pacer-fault
type.)
6, 1
a01b TH_ERROR_DEFIB_WDT_DISABLE_FAIL (Unable to turn off defib WDT; param = ASIC defib ctrl register.)
6, 1
a020 TH_ERROR_PACER_DISABLE (Pacer disabled; cannot communicate with processor.)
6, 1
a021 TH_ERROR_CAP_CHARGE_FAIL (Cap. stays zero while charging. No charge; param = defib setting.)
6, 1
a022 TH_ERROR_CORRUPT_ENERGY_SELECT (Energy select corrupt; param = main energy selection.)
6
a023 TH_ERROR_XFER_ENABLE_ON (Defib transfer-enable line high unexpected. Defib transfer-enable line was not off during startup.)
6, 1
a024 TH_ERROR_VCAP2_SATURATED (VCAP2 reading full scale all the time. Reading not processed.)
6, 1
a026 TH_ERROR_ENERGY_RESIDUE (There is still energy on the cap.)
6, 1
a027 TH_ERROR_PA_RATE_CORRUPT (Pacing rate storage corrupted; param: high-16 = rate selected, low-16 = actual rate.)
15
a028 TH_ERROR_CAL_ENERGY_FAIL (Calibrated voltage is out of range; param: high-16 = table index, low-16 = voltage count.)
6, 1
a029 TH_ERROR_BTE_FAIL (Error condition with BTE board; param: high-16 bits = fault type, low-16 bits = cedar state.)
17, 1
a02b TH_ERROR_DEFIB_CONFIG (Conflicting defib type. Cold boot if test bit set; otherwise, disable biphasic; param = test-bit setting.)
28
a02c TH_ERROR_DUMP_LINE_FAIL (One of dump lines failed; param = test ID.)
19
Table 5.13—Initial Character a, Therapy Service Codes (TH)
Code Service Code Description
Corrective
Action Code
