LIFEPAK 15 Monitor/Defibrillator
Service Manual
Troubleshooting
Therapy Service Codes
Section Menu Section Contents Back Index
132
5
a02d TH_ERROR_WRONG_DEFIB_TYPE (Wrong Defib. type for software.)
28, 11
a02e TH_ERROR_ADC_READ (ADC read failure when getting cap charge.)
28
a101 DE_ERROR_LONG_WDT
(Long watchdog test failed or watchdog did not reset in time.)
7, 10
a102 DE_ERROR_SHORT_WDT (Short watchdog test failed.)
10
a103 DE_ERROR_SCI_RCV (Serial port receiver error.)
10
a104 DE_ERROR_XFER_KEY (Defib HW error.)
10
a106 DE_ERROR_ENERGY_OUT_OF_BOUND (VCAP-1 over/under charge.)
28, 10
a107 DE_ERROR_HP_ENG_SELECT (Cannot determine the rotary setting.)
10
a109 DE_ERROR_CAL_CRC (Calibration Table CRC error.)
10
a10b DE_ERROR_CHG_TIME (Takes too long to reach charge.)
10
a10c DE_ERROR_CHG_ENABLE (CHG_EN1 is stuck high.)
11, 10
a10d DE_ERROR_DUMP_ENERGY (Defib HW error.)
10
a10e DE_ERROR_RCV (Defib HW error.)
10
a111 DE_ERROR_ENERGY_NOT_ZERO (Unexpected energy while biphasic is in high-pot test.)
10
a112 DE_ERROR_TEST_XFER_ENABLE (Problem with transfer; turn on at main.)
10
Table 5.13—Initial Character a, Therapy Service Codes (TH)
Code Service Code Description
Corrective
Action Code
