LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
Installing the System (A01)/Therapy (A04) PCB Assembly
Section Menu Section Contents Procedures Back Index
241
8
9. Connect the W20 - BTE cable to the biphasic PCB at J106.
To install the system/therapy PCB: (Continued) 15 steps, (Page 3 of 5)
W20 flex cable -
J51
W20 flex cable -
J106
Figure 8.42—W20 flex cable connections
W20 flex cable -
J106
To Next Page
