LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
Biphasic Module (A22)/Inductive Resistor (A14) Replacement
Section Menu Section Contents Procedures Back Index
301
8
11. Continue to remove the biphasic PCB from the bracket as follows:
a. Orient the PCB bracket as shown in the diagram (with the mounting
tabs on top and one PCB mounting hole in the upper right corner).
b. Slide the PCB to the right slightly.
c. Rotate the PCB counterclockwise to clear the tab at the lower right
corner.
d. Pull the PCB to the right as you lift it out.
12. Remove the remaining spade terminal wires for use on the replacement
module.
To remove the biphasic module and/or the inductive resistor from the rear case (refer to Inside Rear Case Diagrams (p. 228)):
(Continued) 12 steps, (Page 3 of 3)
