LIFEPAK 15 Monitor/Defibrillator
Service Manual
Replacement Procedures
Coin Battery Replacement
Section Menu Section Contents Back Index
363
8
To replace the coin battery on the system PCB (A01) in the rear case (refer to Inside Rear Case Diagrams (p. 228)):
1. Disassemble the case as described in Disassembling the Case (p. 181).
2. With the new coin battery, (202305-000) (type CR2032), at hand, lift up from below the coin battery to remove. The coin battery
will pop out of the holder. To install, slide in the new battery with (+) terminal up, place battery into right side of battery holder
first. Press down to secure (see Figure 8.124 on p. 362).
3. Reentry of time and date will be required after the coin battery replacement.
4. The coin battery should be part or a five year replacement schedule (see Scheduled Replacement Items (p. 149)).
