LIFEPAK 15 Monitor/Defibrillator
Service Manual
Device Description
Physical Description and Features
Section Menu Section Contents Back Index
58
3
11
button — Accesses optional functions. The options menu selections are: PATIENT, PACING, DATE/TIME, ALARM
VOLUME, ARCHIVES, PRINT, and USER TEST.
12
button — Accesses pre-defined and user-defined events.
13
HOME SCREEN button — Returns to Home Screen display or to previous menu.
14
button and LED — Turns device ON or OFF. LED illuminated when ON. Press and hold to turn device off.
15
button — Increase or decrease defibrillator energy level in Manual mode. Energy levels are from 2 joules to
360 joules.
16
button — Charges the defibrillator in Manual mode. QUIK-COMBO or hard paddles must be attached. When
operating with hard paddles, use the
CHARGE button on the APEX paddle. If the device is in pacing mode, pressing this
button deactivates Pacing Mode and charges the device.
17
SHOCK button and LED — Initiates discharge of defibrillator energy in either AED mode or Manual mode. The LED
flashes when the device is fully charged. When operated with hard paddles, pressing both
SHOCK buttons on the paddles
discharge energy.
18
button and LED — Activates pacer function. LED illuminated when function is activated and flashes with each
current pulse.
19
button — Increases or decreases pacing rate. The up or down arrows on button adjusts the pacing rate in 10 ppm
increments, or rotate the
SPEED DIAL to change the rate in 5 ppm increments.
20
button — Increases or decreases pacing current. The up or down arrows on button adjusts the pacing current in
10 mA increments, or rotate the
SPEED DIAL to change the current in 5 mA increments.
Table 3.1— Front Panel Area 1 Features (Continued)
