LIFEPAK 15 Monitor/Defibrillator
Service Manual
Device Description
Physical Description and Features
Section Menu Section Contents Back Index
57
3
Table 3.1— Front Panel Area 1 Features
Number Description
0
VF dose label — Physio-Control recommended energy dose for adult
Ventricular Fibrillation (VF)
1
Service LED — Illuminates when service error codes are written into the Service Log (accessed in the Service/Status
menu, see Displaying the Service/Status Submenu (p. 106)). See Troubleshooting (p. 98) for information about error codes.
2
Battery charging indicator (V2 only) - LED illuminated when installed batteries are fully charged. LED flashes when either
battery is charging. LED is not illuminated when no batteries are installed or a battery is unable to be charged.
3
Auxiliary power indicator (V2 only) - LED illuminated when defibrillator is connected to auxiliary AC or DC power source, whether
defibrillator is turned on or off.
4
button and LED — Controls CPR metronome. LED is illuminated when metronome function is active.
5
button and LED — Activates the Shock Advisory System (SAS) in AED mode. The LED is illuminated when the SAS
is active and flashes when user is prompted to press
ANALYZE.
6
button — Changes ECG size.
7
button — Changes ECG lead or lead set.
8
button and LED — Activates synchronized cardioversion in Manual mode. The LED is illuminated when active.
When synchronized, the LED flashes with each detected QRS complex.
9
button (optional) — Initiates blood pressure measurement. LED is illuminated when BP measurement is being
obtained.
10
button and LED — Open alarms menu or silences alarms. The LED is illuminated when alarms are enabled and
flashes when an alarm condition occurs.
