Physio Control LIFEPAK 15 - Physical Description and Features

LIFEPAK 15 Monitor/Defibrillator
Service Manual
Device Description
Physical Description and Features
Section Menu Section Contents Back Index
56
3
Click the appropriate number below to view a description of that feature. See area 2 in Figure 3.3 (p. 60).
Figure 3.2—Front panel area 1
