LIFEPAK 15 Monitor/Defibrillator
Service Manual
Device Description
System Context Diagrams
Section Menu Section Contents Back Index
72
3
The following diagram illustrates how the device connects to invasive pressure or temperature equipment.
Figure 3.7—Device connection with invasive pressure or temperature equipment
P1 and P2
connection - OEM
invasive pressure
adapter cable
examples of OEM
invasive pressure
transducers
P2
Temperature or P1
Accessory cable -
Temperature adapter
cable
Measurement
Specialties 4400 Series
disposable temperature
probe
