Wiring
Operating Manual PMCprotego D.48, PMCprotego D.72
1001735-EN-04
113
Fuses – Use in CE regions
Mains voltage power
supply
Voltage class of DC
fuse Device type D.48, D.72
230 V Min. 250 VDC 100 A
400 V Min. 440 VDC 100 A
480 V Min. 600 – 1000 VDC 100 A
Conductor cross section -- 35 mm
2
Fuse type
} With VBUSBAL 0, 1, 2 (230V – 400V):
e.g. fuse type class gRL (gS) from Siba, size 22 x 58 AC 690/700 V and DC 440V,
30kA
} With VBUSBAL 2 qnd 3 (400 – 480 V):
e.g. fuse type class aR from Siba, size 14 x 51 mm DC 700 V, 30/50 kA
Fuse holder
2-pin fuse holder (finger-safe design):
} 14 x 51 mm: Siba, Part No: 51 058 04.2
} 22 x 58 mm: Siba, Part No: 51 060 04.2
Fuses – Use in UL-cUL regions
Mains voltage
power supply
Voltage class of DC
fuse Device type D.48, D.72
230 V Min. 250 VDC 100 A
400 V Min. 440 VDC 100 A
480 V Min. 600 – 1000
VDC
100 A
Conductor cross sec-
tion
-- 35 mm
2
Fuse type
Bussmann:
} up to 100 A: FWP-zzzA22F, size 22 x 58 mm with 500 Vdc UL approval
Fuse holder
Bussmann:
} CH142D, CH222B
