Technical details PMCprotego D.48
Operating Manual PMCprotego D.48, PMCprotego D.72
1001735-EN-04
201
Power element
Clock frequency of inverted rectifier
In normal mode 8 kHz
With current reduced to 50 % 16 kHz
Form factor of continuous output current at min. wind-
ing inductance 1,01
Rated intermediate circuit voltage 260 - 900 V
Max. rated intermediate circuit voltage 900 V DC
Power dissipation at max. mains voltage
Without brake 635 W
With inverted rectifier switched off 24 W
Brake chopper power element
Switch-on threshold
at 230 V 400 V
at 400 V 720 V
at 480 V 790 V
Max. overvoltage, intermediate circuit
at 230 V 455 V
at 400 V 800 V
at 480 V 900 V
Pulse brake power
at 230 V 16 kW
at 400 V 50 kW
at 480 V 70 kW
External brake resistor Rbe 15 Ohm
Continuous output RBe 6 kW
STO-ENABLE
Number 2
Input voltage 20 - 30 V
Input current at signal level "1" 33 - 40 mA
Reaction time STO1-ENABLE 5 ms
Reaction time STO2-ENABLE 5 ms
Resolver input
Number 1
Connection type 9-pin D-Sub female connector
SinCos encoder input, incremental encoder
Number 1
Connection type 15-pin D-Sub female connector
Analogue inputs
Number of analogue inputs 2
Type of analogue inputs Voltage
Input area -10 ... 10 V
Resolution 16 Bit
Max. common mode voltage -10 - 10 V
Input resistance 150 kOhm
