Technical details PMCprotego D.48
Operating Manual PMCprotego D.48, PMCprotego D.72
1001735-EN-04
202
Analogue inputs
Scan rate 16 kHz
Inputs
Number 4 - 6
Scan rate DIGITAL-IN-1 and 2 500 kHz
Scan rate DIGITAL-IN 3 and 4 4 kHz
Signal level at "0" -3 - +5 V DC
Signal level at "1" 15 - 30 V DC
Input current at signal level "0" 1 mA
Input current at signal level "1" 2 - 15 mA
Input voltage in accordance with EN 61131-2 Type 1 24 V DC
Potential isolation between input and internal module
bus voltage yes
Semiconductor outputs (standard)
Number 2
Switching capability
Current 0,1 A
Galvanic isolation yes
Relay outputs
Operational readiness function
Number 1
Max. voltage AC 42 V
Max. voltage DC 30 V
Max. current 500 mA
CANopen interface
Number 1
Connection type 9-pin D-Sub male connector
Ethernet interface
Connection type RJ45
Serial interface
Number of RS232 interfaces 1
Communication interfaces
RS232 and CANopen, on the same connector
Connection type 9-pin D-Sub male connector
Environmental data
Ambient temperature
In accordance with the standard DIN EN 60721-3-3
Temperature range 0 - 40 °C
Temperature range with power derating 40 - 55 °C
Power derating 2,5 %/K
Storage temperature
In accordance with the standard DIN EN 60721-3-1
Temperature range -25 - 55 °C
Max. change 20 K/h
Storage temperature class 1K4
