User’s Manual of WGSD-10020 Series
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.8.9 MLD Snooping VLAN Configuration
Each page shows up to 99 entries from the VLAN table, default being 20, selected through the "entries per page" input field.
When first visited, the web page will show the first 20 entries from the beginning of the VLAN Table. The first displayed will be
the one with the lowest VLAN ID found in the VLAN Table.
The "VLAN" input fields allow the user to select the starting point in the VLAN Table. The MLD Snooping VLAN Configuration
screen in Figure 4-8-12 appears.
Figure 4-8-12 IGMP Snooping VLAN Configuration page screenshot
The page includes the following fields:
Object Description
• VLAN ID
The VLAN ID of the entry.
• MLD Snooping Enable
Enable the per-VLAN MLD Snooping. Only up to 64 VLANs can be selected.
• MLD Querier
Enable the MLD Querier in the VLAN.
• RV
Robustness Variable. The Robustness Variable allows tuning for the expected
packet loss on a link. The allowed range is 1 to 255, default robustness variable
value is 2.
• QI
Query Interval. The Query Interval variable denotes the interval between General
Queries sent by the Querier. The allowed range is 1 to 255 seconds, default
query interval is 125 seconds.
• QRI
Query Response Interval. The Maximum Response Delay used to calculate the
