4.16 Power over Ethernet (WGSD-10020HP)
Providing up to 8 PoE, in-line power interface, the WGSD-10020HP PoE Switch can easily build a power central-controlled IP
phone system, IP Camera system, AP group for the enterprise. For instance, 8 camera / AP can be easily installed around the
corner in the company for surveillance demands or build a wireless roaming environment in the office. Without the power-socket
limitation, the PoE Switch makes the installation of cameras or WLAN AP more easily and efficiently.
Figure 4-16-1 Power over Ethernet Status
4.16.1 Power over Ethernet Powered Device
3~5 watts
Voice over IP phones
Enterprise can install POE VoIP Phone, ATA and other Ethernet/non-Ethernet
end-devices to the central where UPS is installed for un-interrupt power system
and power control system.
6~12 watts
Wireless LAN Access Points
Museum, Sightseeing, Airport, Hotel, Campus, Factory, Warehouse can
install the Access Point any where with no hesitation
10~12 watts
IP Surveillance
Enterprise, Museum, Campus, Hospital, Bank, can install IP Camera without
limits of install location – no need electrician to install AC sockets.
