User’s Manual of WGSD-10020 Series
7.5 Auto-Negotiation
The STP ports on the Switch have built-in "Auto-negotiation". This technology automatically sets the best possible bandwidth
when a connection is established with another network device (usually at Power On or Reset). This is done by detect the modes
and speeds at the second of both device is connected and capable of, both 10Base-T and 100Base-TX devices can connect
with the port in either Half- or Full-Duplex mode.
If attached device is: 100Base-TX port will set to:
10Mbps, no auto-negotiation 10Mbps.
10Mbps, with auto-negotiation 10/20Mbps (10Base-T/Full-Duplex)
100Mbps, no auto-negotiation 100Mbps
100Mbps, with auto-negotiation 100/200Mbps (100Base-TX/Full-Duplex)
