User’s Manual of WGSD-10020 Series
486
disable : Disable DSCP egress rewrite
enable : Enable DSCP egress rewrite with the value received from analyzer
remap_dp_unaware : Rewrite DSCP in egress frame with remapped DSCP where remap is DP unaware or DP = 0
remap_dp_aware : Rewrite DSCP in egress frame with remapped DSCP where remap is DP aware and DP = 1
(default: Show port DSCP egress remarking mode)
Default Setting:
disable
Example:
Enable DSCP egress rewrite
WGSD
-10020HP:/> QoS Port DSCP EgressRemark 1-10 enable
QoS DSCP Map
Description:
Set or show DSCP mapping table.
This table is used to map QoS class and DP level based on DSCP value.
DSCP value used to map QoS class and DPL is either translated DSCP value or incoming frame DSCP value.
Syntax:
QoS DSCP Map [<dscp_list>] [<class>] [<dpl>]
Parameters:
<dscp_list>: DSCP (0-63, BE, CS1-CS7, EF or AF11-AF43) list or 'all'
(default: Show DSCP ingress map table i.e. DSCP->(class, DPL))
<class> : QoS class (0-7)
<dpl> : Drop Precedence Level (0-1)
QoS DSCP Translation
Description:
Set or show global ingress DSCP translation table.
If port DSCP translation is enabled, translation table is used to translate incoming frames DSCP value and translated
value is used to map QoS class and DP level.
Syntax:
QoS DSCP Translation [<dscp_list>] [<trans_dscp>]
