User’s Manual of WGSD-10020 Series
Object Description
• IPv6 Address
The destination IPv6 Address.
• Ping Size
The payload size of the ICMPv6 packet. Values range from 8 bytes to 1400
bytes.
Buttons
: Click to transmit ICMP packets.
4.15.3 Remote IP Ping Test
This page allows you to issue ICMP PING packets to troubleshoot IP connectivity issues on special port.
After you press “Test”, 5 ICMP packets are transmitted, and the sequence number and roundtrip time are displayed upon
reception of a reply. The page refreshes automatically until responses to all packets are received, or until a timeout occurs. The
ICMP Ping screen in Figure 4-15-3 appears.
Figure 4-15-3 Remote IP Ping Test page screenshot
The page includes the following fields:
Object Description
• Port
The logical port for the settings.
